BIOMETRIC ACCESS CONTROL SYSTEM AI-Powered Face Recognition Device

BIOMETRIC ACCESS CONTROL SYSTEM AI-Powered Face Recognition Device

Dynamic Face, Fingerprint, Card and Password Recognition. VM-AI06QR is Widely Used in
Passenger Turnstile, Government Institution, Office, Building Apartment, Community,
College and Various Enterprise etc.

Product Details:

Board:	Varito
Model	VM-AI06F
Display	HD Touch Screen
Screen size	4.3 Inch, Capacitive touch screen
Verify Method	Face, Card, QR Code, Password
Operation:	LINUX 3.10 System

Datasheet Request a Quote

Many Features

Product

AI Dynamic Face Recognition, Time attendance, Access control Terminal

Display

4.3 Inch Touch Screen, HD 1280*720, Capacitive Touch Screen

Verification

Dynamic face recognition, password, ID/IC card optional

Face /Password Capacity

5,000 (20,000 Optional)

Prevent Photo

Dual camera anti-counterfeiting, prevent recognition with photo/video

Face attendance software

Support exporting excel attendance report with U disk

Multi language

English, Spanish, Arabic, Thai, Japanees, Korean etc

Working current

Stand-by current: 310mA, Working current: 520mA

Specification

Item	Details
Model No.	VM-AI06F
Brand	Varito
Product	AI Dynamic Face Recognition, Time Attendance, Access Control Terminal
CPU, NPU	1.2G Dual-Core ARM Cortex-A7, 600G (0.6T)
Keypad	Touch keypad
RAM	256MB DDR3L
ROM	eMMC Flash 4G
Binocular Camera	200W Colorful WDR + 200W Infrared live camera
Logs Capacity	50,000
Display	4.3 inch Touch Screen, HD 1280×720, Capacitive Touch Screen
Operation System	Linux 3.10
Face Registration	Local operation: Enroll face with machine, import user photo with U disk. Software operation: Import user photo to software, capture user photo with camera
Verification	Dynamic face recognition, password, ID/IC card optional
Face / Password Capacity	5,000 (20,000 optional)
Fingerprint Capacity	10,000 (20,000 optional)
Card Capacity	15,000 (20,000 optional), ID Card standard, IC Card Mifare 13.56MHz
Password Capacity	15,000 (20,000 optional)
Face Recognition Accuracy	99.7%
Recognition Speed	<0.2s, supports single/multi-user (max 5 users at same time)
Recognition Distance	0.5–2.5 meters (0.5–1.5 meters with live face recognition on)
Prevent Photo	Dual camera anti-counterfeiting, prevent recognition with photo/video
Principle of Identification	Face algorithm technology of multi-task cascaded convolutional neural network based on video stream for dynamic face detection, tracking and recognition
WDR	Wide dynamic range, accurate face recognition under strong light, dark light and backlight
USB	USB 2.0 ×1, support U-disk import/export data
Power Supply	DC12V interface ×1
Speaker Interface	Reserved for extended speaker interface
Network Communication	TCP/IP support C/S LAN communication, WiFi (optional)
Face Attendance Software	Support exporting Excel attendance report with U disk
Shift	Support shift setting and importing shift schedule with U disk
Management Software	Support PC software to manage data through network connection with equipment
Access Control Function	Door unlocked alarm, forced door opening linkage and output, one set of door opening signals, one set of alarm signals, time permission control, connect external access control reader, Wiegand 26/34 output
Environmental Adaptability	Working temperature: -15°C~+50°C (storage: -40°C~+60°C) Working humidity: 20%~90% (storage: 20%~90%) Dark environment: LED soft light automatic fill light Ambient light adaptation range: 0~50,000 Lux
Multi Language	English, Spanish, Arabic, Thai, Japanese, Korean etc.
Broadcast and Ring	Support display name, voice broadcast name, built-in bell ring
Automatic Fill Light	Support infrared fill light, white fill light automatically lights up in dark environment
Working Current	Standby: 310mA, Working: 520mA
QR Code Scanner	Support
Working Voltage	DC12V
Installation Way	Wall mount (standard), Desktop stand (optional), Bracket for turnstile, Floor stand
Machine Dimension	187.5 × 87.5 × 26 mm
